ARINC 429 Test Equipment
ARINC 429 test equipment transmits, receives and monitors ARINC 429 labels so that avionics engineers can test line-replaceable units on the bench, simulate missing aircraft systems and capture bus traffic for troubleshooting. ARINC 429 runs point-to-point at 12.5 kbit/s (low speed) or 100 kbit/s (high speed) [1]. Novatelia sources selected ARINC 429 interfaces by RFQ for customers in Oman and qualified GCC projects.
Applications
- Bench test and acceptance of ARINC 429 LRUs [1].
- Simulation of transmitting aircraft systems with programmable labels and rates [1].
- Real-time recording and analysis of label traffic [2].
Equipment types
- PC interface cards: PCIe, PCI, PMC, XMC, PXI/cPCI [3][1].
- Real-time Ethernet and USB converters in rugged cable-in-line packages, e.g. Alta NLINE-EA429 [3].
- Mixed 1553 + ARINC 429 modules [3][4].
Technologies
- Software-selectable Rx/Tx channels and baud rates [2].
- Related protocols on the same hardware: ARINC 419, 575, 573 and 717 on Alta PMC-A429 [2].
- Error injection and detection on AIM ARINC 429 modules [1].
How to select equipment
- Count Rx and Tx channels: Alta PCIe4L-A429 offers 4–30 channels (up to 16 shared Rx/Tx plus 14 Rx) [3].
- Choose the host: desktop PC, PXI chassis, laptop via USB/Thunderbolt, or Ethernet [3].
- Check if you also need ARINC 717 flight-data or MIL-STD-1553 on the same card [2][3].
Customer types
- Avionics component shops
- Integration and test laboratories
- Flight-test and data-acquisition teams
Relevant standards
- ARINC 429 (ARINC/SAE-ITC) – digital information transfer system [1].
- ARINC 717 – flight data acquisition, supported on some ARINC 429 cards [2].
Brands
AIM GmbH
AIM develops avionics databus test, simulation, monitoring and analysis modules and the PBA.pro analyzer software for MIL-STD-1553, ARINC 429, AFDX/ARINC 664P7, ARINC 825, Fibre Channel and other aircraft buses…
Aircraft Network & Data Bus TestingARINC 429 Test Equipment
Alta Data Technologies
Alta Data Technologies makes MIL-STD-1553 and ARINC 429 interface cards and real-time Ethernet and USB converters for avionics test, simulation and embedded use…
ARINC 429 Test EquipmentAircraft Network & Data Bus Testing
Astronics Ballard Technology
Astronics Ballard Technology, now part of Astronics AES, makes avionics databus test and simulation interfaces for MIL-STD-1553, ARINC 429/708/717, Ethernet, serial and discrete I/O, used with its CoPilot software…
Aircraft Network & Data Bus TestingARINC 429 Test Equipment
Tektronix
Tektronix makes oscilloscopes and test instruments. Its SRAERO option adds MIL-STD-1553 and ARINC 429 triggering, decoding and search to 3 Series MDO and 4/5/6 Series MSO oscilloscopes …
Aircraft Network & Data Bus TestingARINC 429 Test EquipmentAvionics Test Equipment
Curtiss-Wright
Curtiss-Wright supplies flight test instrumentation. Its Axon data acquisition unit is modular and can monitor aircraft avionics buses during flight test …
Aircraft Network & Data Bus TestingARINC 429 Test Equipment
Products
Alta Data TechnologiesARINC 429 Test EquipmentRFQ
Alta Data PCIE4L-A429 ARINC 429 PCIe Interface
Model: PCIE4L-A429
- 4–30 ARINC channels
- Up to 16 shared Rx/Tx and 14 Rx channels
- Standard half-size PCIe, 4-lane
- Part of a family also available in PCI, PMC and XMC
Status: Request a quote · calibration certificate on request
AIM GmbHAircraft Network & Data Bus TestingRFQ
AIM ANET-MxAy MIL-STD-1553 / ARINC 429 Ethernet Test Module
Model: ANET-MxAy
- 1553 section acts concurrently as BC, 31 RTs and chronological/mailbox monitor
- ARINC 429 channels software-programmable for Rx or Tx
- Full error injection and detection on both protocols
- 8 general-purpose discrete I/O signals
Status: Request a quote · calibration certificate on request
Oman & GCC support
For arinc 429 test equipment, Novatelia handles sourcing, quotation and delivery coordination from Muscat for Oman customers and on a project basis for other GCC countries; see Aviation supply in Oman. Novatelia does not claim local OEM service centres or civil aviation authority approvals.
Related aviation categories
Frequently asked technical questions
What speeds does ARINC 429 use?
12.5 kbit/s low speed and 100 kbit/s high speed [1].
Can one card handle ARINC 717 too?
Some can; Alta PMC-A429 supports ARINC 419/429/575/573/717 configurations [2].
Request a quote
Send part numbers, quantities, delivery location and any calibration or documentation requirements for arinc 429 test equipment. Quotes depend on manufacturer channel rules, export conditions and availability.
