Avionics Test Equipment Guide

This overview guide maps the main avionics test equipment types to the tasks they support, linking to the detailed guides. It cites FAA regulations and OEM data sheets.

Ramp test sets

• Multi-function sets test transponder, ADS-B, TCAS, NAV and COM, e.g. VIAVI AVX-10K ^[1].
• Transponder tests under 14 CFR 91.413 ^[2].

Pitot-static and air data

• Air data test sets support altimeter and static system checks under 14 CFR 91.411 ^[3][4].

Databus testing

• ARINC 429 and MIL-STD-1553 interfaces for bench testing ^[5][6].

Products referenced in this guide

• VIAVI SolutionsAvionics Test EquipmentRFQ



  VIAVI AVX-10K Flight Line Test Set

  Model: AVX-10K

  • Transponder Auto tests incl. FAR Part 43
  • ADS-B Auto tests per AC 20-165 and CS-ACNS
  • Up to five static 1090 MHz ADS-B/ADS-R/TIS-B targets
  • TCAS I/II, TAS, E-TCAS intruder scenarios

  Status: Request a quote · calibration certificate on request

• LaversabPitot-Static & Air Data Test EquipmentRFQ



  Laversab Model 6300 RVSM Pitot-Static Tester

  Model: 6300

  • Automatic ramping to altitude/airspeed set-points, stable within ±1 ft and ±0.1 kt
  • 15 stored profiles × 50 set-points
  • Independent or simultaneous pitot/static leak checks with three timers
  • Programmable limits and negative-airspeed protection

  Status: Request a quote · calibration certificate on request

Related category

Avionics Test Equipment · All aviation guides

Frequently asked questions

Which guide covers ADS-B?

The transponder and ADS-B testing guide.

Do test sets need calibration?

Yes, per your calibration programme; see the Aviation Calibration Guide.

This guide is general information. It does not replace the aircraft maintenance manual, the operator's approved procedures or the rules of the competent civil aviation authority.

Request a quote

Send part numbers, quantities, delivery location and any calibration or documentation requirements for avionics test equipment guide. Quotes depend on manufacturer channel rules, export conditions and availability.

Add to RFQ – contact Novatelia or email [email protected]

Sources

1. VIAVI AVX-10K Commercial Flight Line Test Set selection guide (PDF)
2. 14 CFR 91.413 – ATC transponder tests and inspections
3. 14 CFR 91.411 – Altimeter system and altitude reporting equipment tests and inspections
4. Laversab Model 6300 RVSM pitot-static tester – product page
5. AIM – ARINC 429 bus interfaces
6. Alta Data Technologies – ARINC interface products
