Overview

Key features Increased sensitivity to visualize temperature differences Easier to visualize and diagnose issues with sharper onscreen images, multiple rectangle markers and 9 color palettes More intuitive visual interface, improved, user-tested, touch screen interface More flexibility to visualize target, tiny-to-large with interchangeable smart lenses - no calibration required, 2x and 4x telephoto, wide angle and macro lens compatibility Capture a clear, accurate image focused throughout the field of view with MultiSharp™ Focus Get an instant in-focus image of your designated target. LaserSharp® Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target. Get 4x the pixel data with SuperResolution, which captures multiple images and combines them to create a 1280 x 960 image Save time - wirelessly sync images directly from your camera to the Fluke Connect® system, and attach to an asset record or work order Reduce the need take notes in the field with IR-PhotoNotes™ and voice annotations Product overview: Increased sensitivity to visualize differences Capture smaller temperature differences with increased thermal sensitivity Easier to visualize and diagnose issues Sharper onscreen images with better visual color differentiation Display deviations from standard temperatures and communicate issues with your team using multiple Delta-T markers - choose one as a reference point and the others to display a value as a difference Multiple rectangle markers in-camera - identify min\/max temperatures for an area of the equipment or an equipment array Distinguish heat differences more easily with a new palette and a wider array of yellows and greens in the display More intuitive visual interface Improved, user-tested, touch screen interface leverages current styles and is more intuitive than ever More flexibility to visualize targets - tiny to large Now compatible with all Fluke infrared smart lenses Macro, telephoto and wide angle – from tiny to large, capture your target Fluke smart lenses are interchangeable between compatible cameras without calibration With the Ti480 PRO MultiSharp™ focus captures images that are focused throughout the field of view, even if you start from a completely blurry target. The camera takes multiple images and combines them to give a clear, accurate focus on targets near and far. See more detail with SuperResolution, offering 4x the pixel data. Using the software and SuperResolution you can view images with up to 1280 x 960 resolution. Save time with the Fluke Connect® system You can wirelessly sync images directly from your camera to the Fluke Connect® system, and attach it to an asset record or work order. Having access to maintenance records simultaneously at the inspection site and from the office or an off-site location enables faster decision making and real time collaboration between team members. You can also live stream the camera display to your smartphone or PC and remotely control the camera. Capture and sa Specifications: Key features IFOV with standard lens (spatial resolution) 0.93 mRad, D:S 1065:1 Detector resolution 640 x 480 SuperResolution Captures and combines 4x the data to create a 1280 x 960 (614,400 pixels) image Infrared Resolution 307,200 pixels MultiSharp™ Focus Yes, focused near and far, throughout the field of view LaserSharp® Auto Focus Yes, for consistently in-focus images Laser distance meter Yes, calculates distance to the target for precisely focused images and displays distance on screen Advanced manual focus Yes Ruggedized touchscreen display 3.5 inch (landscape) 640 x 480 LCD Rugged, ergonomic design for one-handed use Yes Digital zoom 2x and 4x Temperature measurement Temperature measurement range (not calibrated below -10 °C) -10 °C to 1000 °C (14 °F to 1832 °F) Accuracy ±2 °C or 2% (at 25 °C nominal, whichever is greater) Thermal sensitivity (NETD)* 0.05 °C at 30 °C target temp (50 mK) On-screen emissivity correction Yes (both value and table) On-screen reflected background temperature compensation Yes On-screen transmission correction Yes Wireless connectivity To PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available) Fluke Connect® app compatible Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing Fluke Connect® Assets optional software Yes*, assign images to assets and create work o Data sheet: Ti401 PRO, Ti480 PRO, TiX501 and TiX580 Infrared Cameras Manuals: Ti300 PRO, Ti400 PRO, Ti401 PRO, Ti450 PRO, Ti450SF6, Ti480 PRO

Part number

59-28-2480

Brand

Fluke

Category

Tools & Equipment

Product type

Test Equipment
