Overview

Key features True-rms measurements for accuracy when measuring complex, non-sinusoidal waveforms 40 mm jaw opening Highest resolution of 1 A, measure up to 60 A Selectable filter function removes unwanted noise Max/Min/Average readings and hold function Forward-facing LED worklight for use in dark wiring cabinets Backlit display; auto backlight off and auto power off for extended battery life CAT III 600V safety rating Internal Memory Logging: up to 65,000 measurement points Product overview: Reduce downtime – Find leakage currents without taking equipment offline. The Fluke 368 FC true-rms leakage current clamp meter helps users detect, document, record and compare leakage current readings over time as a means of preventing unplanned downtime, and identifying intermittent GFCI and RCD trips, all without taking equipment off line. The Fluke 368 FC has a large 40 mm diameter jaw for work with large conductors. The clamp s jaw is fully shielded to accurately capture very small leakage signals, and to minimize external electromagnetic interference. The 368 FC also offers wireless data connectivity via Fluke Connect. As part of Fluke Connect — the industry s largest system of software and more than 40 wireless test tools — the 368 FC allows you to track changes in leakage current over time, helping to identify potential problems before they turn into major failures. Specifications: Electrical Specifications Measurement function Alternating current AC ampere range 3 mA, 30 mA, 300 mA, 3 A, 30 A, 60 A mA \/ A: manual selection 3 mA \/ 30 mA \/ 300 mA: automatic selection 3 A \/ 30 A \/ 60 A: automatic selection Range \/ Resolution 3 mA \/ 0.001 mA 30 mA \/ 0.01 mA 300 mA \/ 0.1 mA 3 A \/ 0.001 A 30 A \/ 0.01 A 60 A \/ 0.1 A Accuracy – filter activated (40 to 70 Hz), filter off (40 to 1 kHz) 3 mA – 30 A 1% + 5 digits 60 A 2% + 5 digits Frequency 40 Hz to 1 kHz Crest Factor 3 After calibration accuracy is valid for one year. Accuracy is expressed as ± (% of reading + digits). Reference conditions 23 ±5 °C and a maximum relative humidity of 80%. The minimum value is 10 A rms. Outside of the TC \/ °C 18 °C to 28 °C, 0.02 + 1 Physical Display (LCD) Digital readout: 3300 count Display refresh rate 4 times \/ sec Maximum conductor diameter 40 mm Dimensions 234 x 101 x 46 mm Weight 500 g Battery 2 AA, IEC LR6, NEDA 15A, alkaline Battery life Expected battery life, without using backlight and spotlight, is more than 150 hours Automatic shut-down Meter automatically shuts down after 15 minutes of inactivity Safety and Environmental Specifications General safety IEC 61010-1: Pollution Degree 2 Manuals: 368\/369

Part number

59-07-1368

Brand

Fluke

Category

Tools & Equipment

Product type

Test Equipment

Documents
